Audio Technica AE5100 Cardioid Condenser Instrument Microphone

Audio Technica ATW11/ATM75cW AT-ONE Wireless Headset Microphone System
Audio Technica AE3000 Cardioid Condenser Instrument Microphone

$339.00

  • Large-diaphragm cardioid condenser microphone for instruments.
  • Ideal for overheads, percussion, acoustic guitar, and choir.
  • Low-profile design enables flexible placement on stage.
  • Built-in high-pass filter and 10 dB pad for high-SPL sources.
  • Delivers warm, accurate sound for live and studio use.
Categories: , , Brand:

Description

Audio-Technica AE5100 Cardioid Condenser Instrument Microphone is a large-diaphragm condenser microphone engineered for high-quality live sound and studio recording of acoustic instruments. Designed for overheads, percussion, acoustic guitar, strings, and choir applications, the AE5100 delivers rich, warm, and accurate audio with excellent detail.

Its large-diaphragm capsule produces a natural frequency response with low noise and smooth tonal balance, making it suitable for both stage reinforcement and professional recording environments. The cardioid polar pattern focuses on the desired sound source while reducing pickup from the sides and rear, improving isolation in complex live setups.

Despite its studio-grade performance, the AE5100 features a low-profile design that enables flexible placement where traditional large studio microphones cannot fit. This makes it ideal for discreet overhead positioning and close instrument miking without obstructing performers or sightlines.

Built for durability, the microphone includes an isolation clamp for secure mounting and vibration reduction. An integrated 80 Hz high-pass filter helps reduce low-frequency rumble, while a 10 dB pad allows the AE5100 to handle extremely high sound pressure levels without distortion.

Combining robust construction, versatile placement options, and studio-quality sound, the AE5100 is an excellent choice for musicians, sound engineers, and venues requiring reliable large-diaphragm condenser performance.

Key Features

• Large-diaphragm condenser capsule for accurate, natural sound

• Ideal for overheads, percussion, acoustic guitar, strings, and choir

• Cardioid polar pattern for improved isolation

• Low-profile design for flexible placement

• Low noise and smooth frequency response for recording

• Integral 80 Hz high-pass filter

• Switchable 10 dB pad for high-SPL sources

• Rugged construction for reliable live performance use

• Includes isolation clamp for secure mounting

Specification

• Element: Fixed-charge back plate, permanently polarized condenser

• Polar Pattern: Cardioid

• Frequency Response: 20 – 20,000 Hz

• Low Frequency Roll-Off: 80 Hz, 12 dB/octave

• Open Circuit Sensitivity: −36 dB (15.8 mV) re 1V at 1 Pa

• Maximum Input Sound Level: 148 dB SPL (1 kHz at 1% T.H.D.); 158 dB SPL with 10 dB pad

• Noise: 11 dB SPL

• Dynamic Range: 137 dB (1 kHz at Max SPL)

• Signal-to-Noise Ratio: 83 dB (1 kHz at 1 Pa)

• Phantom Power Requirements: 11–52 V DC, 3.2 mA typical

• Switches: High-pass filter; 10 dB pad (nominal)

• Weight: 143 g (5.0 oz)

• Dimensions: 148.5 mm (5.85″) long, 26.0 mm (1.02″) maximum diameter

• Output Connector: Integral 3-pin XLRM-type

• Accessories Included: AT8471 isolation clamp for 5/8″-27 threaded stands; 5/8″-27 to 3/8″-16 threaded adapter; AT8136 windscreen; soft protective pouch

• Audio-Technica Case Style: S4
