Audio Technica AT4060A Cardioid Condenser Tube Microphone
$2,688.00
- Premium cardioid tube condenser microphone with classic vintage sound.
- Wide dynamic range and high SPL handling for vocals and instruments.
- Dual-diaphragm design ensures consistent polar pattern performance.
- Includes dedicated tube power supply and shock mount.
- Ideal for professional studio recording and live applications.
- Description
Description
Audio-Technica AT4060A Cardioid Condenser Tube Microphone is a premium vacuum tube condenser microphone designed for professional studio recording and live performance. This cardioid tube microphone delivers classic vintage warmth while maintaining the accuracy, dynamic range, and reliability required for modern production environments.
The AT4060A captures both subtle vocal nuances and high-SPL sound sources such as guitar cabinets, making it suitable for vocals, instruments, and broadcast recording. Its dual-diaphragm capsule design maintains precise polar pattern definition across the full frequency range, while the gold-sputtered diaphragms undergo a multi-step aging process for long-term stability.
Hand-selected vacuum tubes are individually tested and aged to ensure consistent performance and classic valve character. The regulated heater current minimizes noise contamination, and the large coupling transformer provides superior low-frequency linearity for a smooth, natural sound.
Designed for demanding professional use, the Audio-Technica AT4060A includes a dedicated tube microphone powering unit and custom shock mount for optimal performance and isolation. Each unit is individually tested and inspected for quality assurance, making it a reliable choice for studios seeking vintage tube tone with modern precision.
Key Features
• Premium cardioid tube condenser microphone for studio and live applications
• Classic vintage tube sound with modern performance standards
• Wide dynamic range, low noise, and high SPL handling
• Dual-diaphragm capsule maintains consistent polar pattern accuracy
• Gold-sputtered diaphragms aged for long-term stability
• Hand-selected and individually tested vacuum tubes
• Regulated heater current reduces noise in the signal chain
• Large coupling transformer enhances low-frequency response
• Includes dedicated tube microphone power supply and shock mount
• Individually tested for quality assurance
Specification
• Element: Externally polarized (DC bias) condenser
• Polar Pattern: Cardioid
• Frequency Response: 20 – 20,000 Hz
• Sensitivity: -34 dB (19.9 mV) re 1V at 1 Pa
• Maximum Input Sound Level: 150 dB SPL (1 kHz at 1% T.H.D.); 149 dB SPL (1 kHz at 0.5% T.H.D.)
• Noise: 19 dB SPL
• Dynamic Range: 131 dB (1 kHz at Max SPL)
• Signal-to-Noise Ratio: 75 dB (1 kHz at 1 Pa)
• Power Requirements: AT8560a tube microphone powering unit (100–240V AC)
• Output Connector: 3-pin XLRM-type (on tube microphone powering unit)
• Cable: 7.6 m cable with 6-pin XLR connectors between microphone and power unit; AC power cable
• Dimensions (Microphone): 215.0 mm long; 53.4 mm maximum body diameter
• Dimensions (Power Supply): 212.0 mm W × 131.5 mm D × 46.0 mm H
• Weight (Microphone): 645 g
• Weight (Power Supply): 1.3 kg
