Blackmagic HyperDeck Studio HD Pro

Description

HyperDeck Studio HD Pro

HyperDeck Studio HD Pro is a full-rack, professional broadcast recorder designed for reliable HD and Ultra HD capture in live production, post-production, and broadcast environments. Its larger chassis provides space for two internal SSD slots while retaining dual SD card slots, making media interchange between HyperDeck models seamless and convenient.

The unit features high-quality transport controls, a machined metal search dial with electronic clutch, and dedicated jog, shuttle, and scroll modes for precise control during playback and review. Upgraded XLR timecode connections ensure professional studio integration.

With SDI and HDMI inputs and outputs, RS-422 deck control, reference sync, embedded audio, and Ethernet control via Blackmagic HyperDeck Protocol, HyperDeck Studio HD Pro fits smoothly into existing broadcast workflows while delivering dependable performance.

Key Features

• Full-rack HD/Ultra HD broadcast recorder
• Dual internal SSD slots + dual SD card slots
• Professional transport controls with metal search dial
• RS-422 deck control and timecode over XLR
• SDI and HDMI recording/playback
• Ethernet control via HyperDeck protocol
• USB-C external recording support

• SDI Inputs: 1
• SDI Outputs: 2 + 1 x 3G-SDI Monitor Out
• SDI Rates: 270Mb, 1.5G, 3G, 6G
• HDMI: 1 x HDMI 2.0 In, 1 x HDMI 2.0 Out
• Audio: 16-ch embedded SDI, 8-ch embedded HDMI
• Timecode: 1 x XLR In, 1 x XLR Out
• Reference: Tri-Sync / Black Burst (BNC In & Out)
• Ethernet: 1Gb/s (HyperDeck Ethernet Protocol)
• Computer Interface: USB-C 3.0 (5Gb/s)
• Media Slots: 2 x 2.5” SSD + 2 x SD card slots
• External Recording: USB-C 3.0
• File Systems: ExFAT (Win/Mac) or HFS+ (Mac)
• Video Codecs: ProRes, DNxHD, DNxHR, H.264
• Color Space: Rec.601, Rec.709, Rec.2020 + 3D LUT
• HDR: HLG, ST2084 (300–4000)
• Control: RS-422, SDI start/stop, Timecode run
• Display: Built-in 2.2” LCD with LED indicators
• Power: Internal 100–240V AC + 4-pin XLR 12V DC
• Max Power: 100W
• Rack Size: 1RU
• Operating Temp: 0–40°C
• Storage Temp: −20–60°C
• Humidity: 0–90% non-condensing
